Passivation of substrates with hydrogen to reduce the number of electron traps in the buffer layer at the contact of silicon with Ba1-xSrxTiO3

Dmitry A. Belorusov 1
Dmitry A. Belorusov
,
Evgeniy I. Goldman 1
Evgeniy I. Goldman
,  ,  ,
Vladimir A. Pilipenko 2
Vladimir A. Pilipenko
,
Alina V. Semchenko 3
Alina V. Semchenko
1 Kotelnikov Institute of Radio Engineering and Electronics of the Russian Academy of Sciences (Fryazino Branch), 1 Vvedenskogo Sq., Fryazino, Moscow Region 141120, Russian Federation
2 2
3 State Center “Belmikroanalysis”, Branch of JSC INTEGRAL, Kazinets I.P. Str., 121A, Minsk 220108, Republic of Belarus3 Gomel State University named after Francisk Skorina, 104 Sovetskaya Str., Gomel, 246028 Republic of Belarus
Published 30 December 2024
Communication , Volume 10, Issue 4, 203-206
0
Share
Cite this
GOST
 |
Cite this
GOST
Belorusov D. A. et al. Passivation of substrates with hydrogen to reduce the number of electron traps in the buffer layer at the contact of silicon with Ba1-xSrxTiO3 // Modern Electronic Materials. 2024. Vol. 10. No. 4. pp. 203-206.
GOST all authors (up to 50)
Belorusov D. A., Goldman E. I., Chucheva G. V., Afanasyev M. S., Pilipenko V. A., Semchenko A. V. Passivation of substrates with hydrogen to reduce the number of electron traps in the buffer layer at the contact of silicon with Ba1-xSrxTiO3 // Modern Electronic Materials. 2024. Vol. 10. No. 4. pp. 203-206.
RIS
 |
Cite this
RIS
TY - JOUR
DO - 10.3897/j.moem.10.4.143751
UR - https://moem.colab.ws/publications/10.3897/j.moem.10.4.143751
TI - Passivation of substrates with hydrogen to reduce the number of electron traps in the buffer layer at the contact of silicon with Ba1-xSrxTiO3
T2 - Modern Electronic Materials
AU - Belorusov, Dmitry A.
AU - Goldman, Evgeniy I.
AU - Chucheva, Galina V.
AU - Afanasyev, Mikhail S.
AU - Pilipenko, Vladimir A.
AU - Semchenko, Alina V.
PY - 2024
DA - 2024/12/30
PB - НИТУ МИСИС
SP - 203-206
IS - 4
VL - 10
ER -
BibTex
 |
Cite this
BibTex (up to 50 authors)
@article{2024_Belorusov,
author = {Dmitry A. Belorusov and Evgeniy I. Goldman and Galina V. Chucheva and Mikhail S. Afanasyev and Vladimir A. Pilipenko and Alina V. Semchenko},
title = {Passivation of substrates with hydrogen to reduce the number of electron traps in the buffer layer at the contact of silicon with Ba1-xSrxTiO3},
journal = {Modern Electronic Materials},
year = {2024},
volume = {10},
publisher = {НИТУ МИСИС},
month = {Dec},
url = {https://moem.colab.ws/publications/10.3897/j.moem.10.4.143751},
number = {4},
pages = {203--206},
doi = {10.3897/j.moem.10.4.143751}
}
MLA
Cite this
MLA
Belorusov, Dmitry A., et al. “Passivation of substrates with hydrogen to reduce the number of electron traps in the buffer layer at the contact of silicon with Ba1-xSrxTiO3.” Modern Electronic Materials, vol. 10, no. 4, Dec. 2024, pp. 203-206. https://moem.colab.ws/publications/10.3897/j.moem.10.4.143751.
Views / Visits / Downloads
42 / 42 / 46

Keywords

dangling bond passivation
high-frequency C–V curves
silicon–ferroelectric contact buffer layers

Abstract

The performance of FeRAM non-volatile cells including those on ferroelectric insulating layers requires full-scale development of the field effect at the semiconductor–dielectric interface. The recharging of electron traps concentrated in the buffer layer between the insulator and the wafer impedes the development of the field effect at the interface. A Si wafer has been hydrogen-saturated for suppressing the activity of electron traps in the buffer layer at the ferroelectric–silicon contact. The reference specimen has been another similar wafer not exposed to H2. High-frequency C–V curves of the metal–dielectric–semiconductor structures with Ba0.8Sr0.2TiO3 insulating layers deposited on both wafers have been measured. The capacities of the test specimens have proven to be low sensitive to hydrogen saturation of the wafers. This is accounted for by long-term heating of the silicon wafers at 500–600 °C during ferroelectric deposition. It has been proposed to implant large organic cations into the wafers in order to reduce the concentration of electron traps in the Ba0.8Sr0.2TiO3–Si buffer layers. Those organic cations can be 2–phenylethyl ammonium iodide, 4-chlorophenylethyl ammonium iodide and 4-fluorophenylethyl ammonium iodide which showed good results at passivation of high-performance metal–halogenide perovskite solar cells.
