Charge carrier distribution in the region of charged domain walls in reduced lithium niobate

,  ,  ,  ,  ,  ,
Vladimir P. Ivanov 1
Vladimir P. Ivanov
,  ,  ,
Evelina E. Maksumova 1
Evelina E. Maksumova
1 National University of Science and Technology “MISIS”, 4-1 Leninsky Ave., Moscow 119049, Russian Federation
10.3897/j.moem.10.4.142174
Published 30 December 2024
Communication , Volume 10, Issue 4, 217-226
3
Share
Cite this
GOST
 |
Cite this
GOST
Copy cite
Kislyuk A. M. et al. Charge carrier distribution in the region of charged domain walls in reduced lithium niobate // Modern Electronic Materials. 2024. Vol. 10. No. 4. pp. 217-226.
GOST all authors (up to 50)
Copy cite
Kislyuk A. M., Malinkovich M. D., Ilina T. S., Kubasov I. V., Kiselev D. A., Turutin A. V., Ivanov V. P., Temirov A. A., Kuts V. V., Maksumova E. E. Charge carrier distribution in the region of charged domain walls in reduced lithium niobate // Modern Electronic Materials. 2024. Vol. 10. No. 4. pp. 217-226.
RIS
 |
Cite this
RIS
Copy cite
TY - JOUR
DO - 10.3897/j.moem.10.4.142174
UR - https://moem.colab.ws/publications/10.3897/j.moem.10.4.142174
TI - Charge carrier distribution in the region of charged domain walls in reduced lithium niobate
T2 - Modern Electronic Materials
AU - Kislyuk, Aleksandr M.
AU - Malinkovich, Mikhail D.
AU - Ilina, Tatiana S.
AU - Kubasov, Ilya V.
AU - Kiselev, Dmitry A.
AU - Turutin, Andrei V.
AU - Ivanov, Vladimir P.
AU - Temirov, Alexander A.
AU - Kuts, Viktor V.
AU - Maksumova, Evelina E.
PY - 2024
DA - 2024/12/30
PB - НИТУ МИСИС
SP - 217-226
IS - 4
VL - 10
ER -
BibTex
 |
Cite this
BibTex (up to 50 authors)
Copy cite
@article{2024_Kislyuk,
author = {Aleksandr M. Kislyuk and Mikhail D. Malinkovich and Tatiana S. Ilina and Ilya V. Kubasov and Dmitry A. Kiselev and Andrei V. Turutin and Vladimir P. Ivanov and Alexander A. Temirov and Viktor V. Kuts and Evelina E. Maksumova},
title = {Charge carrier distribution in the region of charged domain walls in reduced lithium niobate},
journal = {Modern Electronic Materials},
year = {2024},
volume = {10},
publisher = {НИТУ МИСИС},
month = {Dec},
url = {https://moem.colab.ws/publications/10.3897/j.moem.10.4.142174},
number = {4},
pages = {217--226},
doi = {10.3897/j.moem.10.4.142174}
}
MLA
Cite this
MLA
Copy cite
Kislyuk, Aleksandr M., et al. “Charge carrier distribution in the region of charged domain walls in reduced lithium niobate.” Modern Electronic Materials, vol. 10, no. 4, Dec. 2024, pp. 217-226. https://moem.colab.ws/publications/10.3897/j.moem.10.4.142174.
Views / Visits / Downloads
53 / 53 / 39

Keywords

bidomain crystal
charged domain wall
conductive atomic force microscopy
diffusion annealing
lithium niobate
reduction annealing

Abstract

Charged domain walls (CDWs) in ferroelectric materials are of interest from both fundamental and applied perspectives due to their unique electrophysical properties, which differ significantly from those of the bulk material. Until recently, research efforts primarily focused on studying these properties, while less attention was given to the finite-thickness regions of CDWs with heterogeneous electrical conductivity. This study proposes a model describing the charge carrier distribution within the conductive region of CDWs. The dependencies of charge carrier concentration and mobility on the distance from the CDW were determined. An analytical expression for current-voltage characteristics, measurable by conductive atomic force microscopy (c-AFM), was also proposed. The model has been experimentally validated using AFM methods.
